Used 2010 Monaco Monarch 33 SFS

Standard Features (2010)

Body Construction

• Laminated Sidewall Construction
• Steel Cage Cockpit Construction
• Smooth Gel Coat Fiberglass Exterior Walls
• Front Molded Fiberglass Caps
• Panaview™ 1-Piece Front Windshield
• Large Chrome Front Grille
• Rear Cap with Large Automotive Style Taillights
• Interior Height 84”
• One-Piece Interior Engine Cover
• Chrome Head Power Heated Remote Exterior Mirrors
• Metal Fuel Door with Lock
• One-Piece Polyethylene Pass-Through Storage Compartment
• Side-Hinged Baggage Doors, All Door Locations
• New Full-Body Paint with Painted Graphics
• Rear Ladder
• Undercoating

• Film Front Protection Mask
• Standard Run Savings Package: Film Front Protection Mask, Hardwood Raised Panel Doors on Refrigerator, 3-Camera Rear Vision System, Central Vacuum System, Front Living Room DVD Player, RV Sani-Con 2 System, 12V Heater in Wet Bay

Chassis, Engine & Suspension (Ford 20,500 LB) (30 SFS)

• 6.8L 3-Valve V-10 Gasoline Engine with Electronic Fuel Injection
• Engine Displacement: 6.8 Liters 415 Cu. In.
• Power: 362 HP; Torque: 457 lbs./ft. Max. Net
• TorqShift 5-Speed Automatic Overdrive Transmission with Tow/Haul Mode
• New Transmission Oil Temperature Gauge
• Fuel Tank Capacity 75 Gallon
• 130 Amp Alternator
• Rear Axle Ratio: 5.38:1
• Stainless Steel Wheel Liners
• Leaf Spring Suspension
• Front and Rear Disc, 4-Wheel Anti-Lock Brakes
• Heavy-Duty Front Track Bar with Bilstein® Shock Absorbers
• Fully Automatic Hydraulic Leveling System
• Prewire for Supplemental Braking System
• 5,000 Lb. Hitch Receiver with Dual Connector 4-Pin or 7-Pin
• SmartStructure II

• 8.1L V-8 Gasoline Engine with Electronic Fuel Injection
• Engine Displacement: 8.1 Liters 496 Cu. In.
• Power: 340 HP; Torque: 455 lbs./ft. Max. Net
• 6-Speed Automatic Transmission with Overdrive
• Fuel Tank Capacity 75 Gallon
• 145 Amp Alternator
• Rear Axle Ratio: 5.13:1
• Stainless Steel Wheel Liners
• Leaf Spring Suspension
• ABS Brake System
• Fully Automatic Hydraulic Leveling System
• Prewire for Supplemental Braking System
• 5,000 Lb. Hitch Receiver with Dual Connector 4-Pin or 7-Pin
• SmartStructure II

• 6.8L 3-Valve V-10 Gasoline Engine with Electronic Fuel Injection
• Engine Displacement: 6.8 Liters 415 Cu. In.
• Power: 362 HP; Torque: 457 lbs./ft. Max. Net
• TorqShift 5-Speed Automatic Overdrive Transmission with Tow/Haul Mode
• New Transmission Oil Temperature Gauge
• Fuel Tank Capacity 75 Gallon
• 130 Amp Alternator
• Rear Axle Ratio 5.38:1
• Wheel/Rims Polished Aluminum Wheels
• Leaf Spring Suspension
• Front and Rear Disc, 4-Wheel Anti-Lock Brakes
• Heavy-Duty Front Track Bar with Bilstein® Shock Absorbers
• Fully Automatic Hydraulic Leveling System
• Prewire for Supplemental Braking System
• 5,000 Lb. Hitch Receiver with Dual Connector 4-Pin or 7-Pin
• SmartStructure II

• 8.1L V-8 Gasoline Engine with Electronic Fuel Injection
• Engine Displacement: 8.1 Liters 496 Cu. In.
• Power: 340 HP; Torque: 455 lbs./ft. Max. Net
• 6-Speed Automatic Transmission with Overdrive
• Fuel Tank Capacity 75 Gallon
• 145 Amp Alternator
• Rear Axle Ratio: 5.86:1
• Aluminum Wheels
• Leaf Spring Suspension
• ABS Brake System
• Fully Automatic Hydraulic Leveling System
• Prewire for Supplemental Braking System
• 5,000 Lb. Hitch Receiver with Dual Connector 4-Pin or 7-Pin
• SmartStructure II

Cockpit

• Fiberglass Automotive Dash with Vinyl Covering with Silver Graphite Metallic Instrument Panel
• In-Dash AM/FM/CD Stereo Radio with Sirius-Ready Compatibility, iPod Control, Aux-in-Conn, SD Card Slot and Weather Band
• Front Power Sunvisors
• Rear Vision System Prep
• Leatherette Pilot and Co-Pilot Cockpit Recliner Seats
• Carpeted Driver and Passenger Floor Mats

• GPS Navigation System
• Six-Way Power Pilot Seat (Required Option)
• Sirius Radio Tuner with Satellite System
• Single Camera Rear Vision System
• 3-Camera Rear Vision System with Cameras in Exterior Mirrors
• Interior Solar Privacy Sunscreens

Appliances & Accessories

• Large Double-Door Refrigerator
• High-Output 3-Burner Cooktop without Oven
• Bi-Fold Range Cover
• Spacesaver Convection Microwave with Touch Control
• 26” LCD Stereo Color TV with Remote Control in Cockpit Overhead (N/A: 33SDD, 34SBD)
• 32” LCD Stereo Color TV with Remote Control on Living Room Wall (33SDD, 34SBD)
• 19” Bedroom Widescreen LCD TV
• Curbside: Exterior Hook-Ups for DSS Dish, Cable, 110V Outlet, Hatch Door to Exterior
• Digital Satellite System Prep
• Curbside: Exterior Gas Line Hook-Up Prep for LP Accessories

• Large Double-Door Refrigerator with Ice Maker 10 Cu. Ft.
• Large Four-Door Refrigerator with Ice Maker (N/A with Pantry) (N/A: 30SFS, 33SFS)
• High-Output Three-Burner Range with Oven
• Washer/Dryer Prep (34SBD)
• Combination Washer/Dryer (34SBD, 36PCT)
• Central Vacuum System
• Front Living Room DVD Player
• Bedroom DVD Player

Interior

• Raised Panel Cabinet Doors
• Black ABS Refrigerator Insert
• New Wallpaper Border Kitchen and Bath
• Heavy-Duty Ball-Bearing Drawer Guides
• Wood Cabinet Drawer Boxes
• Solid Surface Kitchen Countertop Edge Treatment and Backsplash
• Kitchen Countertop Extension with Two Drawers below and 110V Outlet (34SBD)
• Kitchen Countertop Extension (30SFS, 33SDD)
• All Other Countertops (except Kitchen) Laminated with Wood Grain Rubber Edge Treatments
• Kitchen Pantry next to Refrigerator with Full-Height Wire Roll-Out Storage (N/A with Four-Door Refrigerator Option) (N/A: 30SFS)
• Carpeting with Pad in Living Area and Bedroom
• Soft Touch Padded Vinyl Ceiling
• Wood Grain Crown Molding in Bedroom and Living Area
• New Wood Slide-Out Fascia with Wood Inserts
• New Satin Nickel Cabinetry Hardware and Bath Accessories
• Hardwood Framed Pocket Doors with
• Flat Panel Insert, Slide-Bolt Door Latch (N/A: 33SDD, 35SFD)
• Blackout Day/Night Pleated Shades in Living Area and in Bedroom

• New Decors: Urban Loft II, Autumn Trail III and Vintage Gold
• Wood Choice: Newport Cherry II, Champagne Select
• Hardwood Raised Panel Doors on Refrigerator IPO Black ABS Refrigerator Insert

Furniture

• Queen Bed with Nightstands (60” x 74” 30SFS, 33SFS, 34SBD) (60” x 80” 33SDD, 35SFD, 36PCT)
• Arched Back Wood Booth Dinette with Side-Sliding Dinette Tabletop (33SDD, 34SBD, 36PCT)
• Freestanding Dinette with Two New-Style Freestanding Chairs and Two Folding Chairs (30SFS, 33SFS, 35SFD)
• Roadside: New-Style Fabric Comfort Lounge Sofa
• Curbside: New-Style Fabric Love Seat Sofa (35SFD)
• New-Style Leatherette Swivel-Rocker Barrel Chair (33SFS, 34SBD, 36PCT)

• Roadside: Fabric Hide-A-Bed Sofa with Air Mattress
• Roadside: Leatherette Hide-A-Bed Sofa with Air Mattress
• Roadside: Leatherette Ensemble Booth Dinette Includes Leatherette Hide-A-Bed Sofa Selection with Air Mattress (Forward-Facing Seatbelts at Booth Dinette Location N/A with This Option) (33SDD, 34SBD, 36PCT)
• Curbside: New-Style Leatherette Love Seat Sofa IPO Fabric Love Seat Sofa (35SFD)
• Curbside: One Leatherette Euro-Recliner with Ottoman and Wall-Mounted Table IPO Sofa (35SFD)
• Curbside: New-Style Leatherette Swivel Recliner IPO Swivel Rocker Barrel Chair (33SFS, 34SBD)
• Curbside: Leatherette Euro-Recliner with Ottoman IPO Leatherette Swivel Rocker Barrel Chair (33SFS, 34SBD, 36PCT)
• Hallway Bunks with Two Fold-Down DVD Players with Game Hook-Ups and Lights at Each Bunk Location, Two Wireless IR Headphones Included (34SBD)
• Freestanding Dinette with Two New-Style Freestanding Chairs and Two Folding Chairs (33SDD, 34SBD, 36PCT)

Electrical System

• 30 Amp 120V Distribution Panel and Cord (30SFS)
• 50 Amp 120V Distribution Panel and Cord (N/A: 30SFS)
• 60 Amp Electronic 12V Power Converter
• Onan® 4.0 kW Generator (30SFS)
• Onan® 5.5 kW Gas Generator (33SFS, 33SDD, 34SBD, 35SFD, 36PCT)
• Two 6V House Batteries
• Battery Disconnect Switches
• Exterior Power Entry Step with Light
• Water Pump Switch in Service Bay Area and Convenience Center
• Lights in Outside Storage Compartments
• Underhood Utility Light
• Two Recessed Ceiling Map Lights above Cockpit Seats
• Hallway Convenience Center
• Decorative Satin Nickel Lighting

• 50 Amp Energy Management System (N/A: 30SFS)
• 600-Watt Inverter (N/A: 30SFS)

Plumbing and LP Systems

• Two-Hole Hi-Rise Kitchen Faucet with Soap Dispenser
• Central Water Filtration System
• Stainless Steel Bath Lavatory Bowl
• Satin Nickel Bath Lavatory Faucet
• Demand Water System and Water Pump
• 10-Gallon LP Gas/Electric Water Heater with Electronic Ignition
• Winterization Valving System
• Water Heater Bypass Valve
• China Toilet with Sprayer
• Holding Tank Rinsing System
• Insulated Systems Compartment with Easy Access to Hook-Up
• Shower inside Wet Bay with Hot/Cold Water, Shower Head with Shut-Off
• Gravity and Pressurized Water Fill (N/A: 35SFD)
• Contained Storage Area for Sewer Hose
• Shower Faucet

• RV Sani-Con 2 System
• Bathtub Option IPO Shower

Heating Vents and Air Conditioning

• Dual 13.5M BTU Air Conditioner with Ducted Air (N/A: 30SFS)
• Single 13.5M BTU Air Conditioner with Ducted Air (30SFS)
• 31M BTU Electronic Ignition Furnace (30SFS)
• 35M BTU Electronic Ignition Furnace (33SFS, 33SDD, 34SBD, 35SFD, 36PCT)
• New Electronic Dash AC/Heat Climate Control System
• Kitchen 12v Roof Vent
• Bath 12v Roof Vent

• Dual 15M BTU Air Conditioner with Heat Pumps IPO 13.5 (N/A: 30SFS)
• Single 15M BTU Air Conditioner with Heat Pump IPO 13.5 (30SFS)
• Kitchen Powered Attic Fan with Wall Control of Automatic Dome and Fan Power
• Bath Powered Attic Fan with Wall Control of Automatic Dome and Fan Power
• 12V Heater in Wet Bay, Heat Pad on Fresh Tank

• Radius Flush-Mounted Dual Pane Windows Safety Glass Dark Tinted
• Rear Wall Bedroom Window (33SDD, 34SBD, 35SFD, 36PCT)
• Bathroom Window (35SFD, 36PCT)
• 30” Wide Radius Entrance Door with Clear Glass, Roller Shade, Screen Door and Anti-Skid Steps
• Topper Slide-Out Awnings Living Area and Bedroom
• Protecta Glaze Tinted Plexiglas® Skylight in Bathroom
• Awning Rail

• Fire Extinguisher (10BC)
• Deadbolt Lock on Entrance Door
• 120V GFI Protected Circuit, Kitchen, Bath and Exterior
• LP Gas Detector
• Smoke Detector
• Carbon Monoxide Detector
• Pilot and Co-Pilot Three-Point Seatbelts (Lap and Shoulder)
• Third Brake Safety Light
• Egress Window(s)

See us for a complete list of features and available options!

All standard features and specifications are subject to change.
